Our tractor factory produces compact tractor with different horsepower, such as 25HP, 30HP, 40HP, 50HP, 60HP, 70HP, 80HP, 90HP and 100HP compact tractor etc.
First, the mini tractor has been upgraded on the chassis. And this mini tractor can be selected with anti-rollover frame, sunshade and cab to meet the different customized requirements of customers. The mini tractor has the characteristics of compact structure, flexible working and easy handling.
The compact tractor also can be used as a yard tractor, and it can be matched with a yard mower for you to trim and take care of the yard. To achieve a multi-purpose, it has been the customer's first choice for yard tractor.
Perfect after-sales service system will ensure our users have no worries.
Product Advantage
1. Streamlined Hood: The front hood has been fully upgraded with legant and streamlined design. Our mini tractor colors and styles can be specified for customization.
2. Track: The adjustable range of the rear wheel track is 850-1300mm which compact tractor meet various field operations for customers.
3. Ground clearance: With a high ground clearance of 350mm, it can prevent collision with the chassis, which also has strong adaptability to farming operations in different terrains.
4. Seat: The compact tractor is specially equipped with spring seats for excellent shock absorption function. Bring a comfortable working experience. And upgraded floating seats can be optionally selected.
5.Engine: We choose the Laidong brand engine. Strong power, high torque, strong traction, and low fuel consumption.
Product Parameters
| 25HP TE Farm Tractor | |
| Product model | GL254-TE |
| Overall dimensions (mm) | 3740×1530×2530 |
| Wheelbase (mm) | 1870 |
| Minimum usable mass (kg) | 1650(safety rack)/1800(cab) |
| Minimum ground clearance (mm) | 350 |
| Engine emissions | National Second Engine |
| Engine brand | Laidong KM385Z |
| Engine type | Inline 4 cylinder |
| Engine calibration power (KW) | 18.4 |
| Engine calibration speed (r/min) | 2400 |
| Clutch type | 10 inch Single acting clutch, dry clutch |
| Number of gears in the gearbox | 8+2(optional 8+8) |
| Axle | TE |
| Tire specifications | 7.5-16/11.2-28 |
| Power output speed (r/min) | 540/720 |
| Hydraulic lifting system type | Strong pressure dual oil cylinder |
| Maximum lifting force (KN) | ≥6.88 |
| Traction force (KN) | ≥8.68 |
